BallisticSkin™ super-polymer technologies are designated into 3 groups: BS-NEAT, BS-LAM and BS-SM. BS-NEAT may be cast optically clear to a thickness of 1.25″ (31mm) to handle intense hand gun fire at close range with fire-power from multiple rounds of 44 magnum, 9 mm and 45 caliber bullets. As shown in shown Fig. 1 a couple of 45 caliber bullets were stopped at a depth of .375″ into BS-NEAT at close range. BS-LAM is specificially designed for composite builds using numerous inner members such as ultra hard steels, ceramics, kevlar fabrics and ultra-dense engineered thermoplastics. BS-SM is an ultra tough energy absorbing skin used primarily in shrapnel mitigation.

BallisticSkin super-polymer materials are capable of absorbing very high impact energy, extremely high tear resistance and can withstand high heat capacities whereby demonstrating ultimate toughness. The spray version of BallisticSkin (BS-SM) is used to strengthen a variety of military grade substrates used for tranportation vehicles, armorment assemblies and structural building reinforcement as shown in Fig. 2 where BS-SM is sprayed on a high strength very hard steel (Brinnel 60-65) panel at a thickness of 3.6 mm. Shown from the back side, the left hand side shows the dark green BS-SM super-polymer coating strenghthening the hard steel keeping it from shattering into shrapnel and panel failure cracking.

Generally, BallisticSkin™ super-polymers are used in some type of ballistic shielding applications. These materials may be applied to many types of structural substrates which include high strength steel, 6061 Aluminum, high-strength composites, wood laminates, reinforced masonry and concrete. These unique materials provide extreme protection for safe-houses, personnel vehicles, government buildings, armed outposts and special aircraft. For specific applications, please contact our technical support group.

Sprayed samples must be aged 30 days at room temperature prior to shooting.

Please call or email our Technical Support Group for any questions regarding material, application or prospective uses.
