WetSkin Epoxy Primer

Available in stock

Quick Overview

WetSkin Epoxy is a superior slow-setting zero-VOC 100% solids epoxy primer formulated specifically for damp, humid, wet or underwater application conditions. It provides excellent adhesion to cold underground concrete surfaces. It provides good chemical and anti-corrosive resistance against water, mineral acids, alkalies, hydrocarbons and solvents. The unique nature of this epoxy permits its use in extreme environments such as underground concrete facilites, nuclear plants, vaults, water water treatment plants, water and chemical containment facilities, tunnels, industrial chemical plants and fresh water environments.

WetSkin is formulated in as a semi-rigid colorable low odor coating system to accommodate surfaces which exhibit a small degree of flexibility while delivering excellent impact strength. This primer coating may also be used to coat metal, wood, fabrics and composite substrates. Its heavy-duty performance characteristics enable it to be used with many types of construction, precasts, wet-floors or repairs producing an adhesion promoter for many super-polymer elastomers or topcoats such as StormSkin™, BlastSkin™, FireSkin, ChemSkin or family of ClearSkin products.

Please contact our technical support group for specific material systems, substrate application procedures, application equipment, recommended safety gear and clean-up procedures. Refer to MSDS for material and safety standard procedures.

Technical Application Data

WetSkin is a two component 1:1 epoxy mixture exhibiting low viscosity. Application temperatures range 40°F to 100°F. Working time at 75°F is 25 min. depending on amount of added diluting solvent. Primer is dry to the touch in 3 hours with full-cure time developing normally within 5 days. Functional operation temperature ranges from -20°F to 175°F. The coating may be applied by spray equipment, roller or brush. After mixing parts A and B, stir thoroughly and give the mixture a 10 min. induction time prior to application. Final top-coat application surface is glossy smooth. Recommended max wet application film thickness is 16 mils. Coverage at 16 mils is 100 sq. ft./ mixed gal.

Physical Properties

Flex Modulus ASTM D624 430 kpsi
Tensile Strength ASTM D412 8544 psi
Elongation ASTM D412 30%
Hardness Shore D ASTM D2240 60
Salt Spray Resistance ASTM B 117 2000 hours continuous
Mix Ratio, resin:hardener PBV 1:1

Adhesion Results

Adhesion Results of Typical Substrates per ASTM D-4541 Elcometer
Concrete- clean >300 psi Cohesive failure; excellent substrate bonding
Steel- clean >1000 psi Cohesive failure; excellent substrate bonding
Wood- dry/dust free >250 psi Wood failure; excellent substrate bonding

Substrate Surface Preparation

Preparation of substrate surface prior to the application of a SuperSkinSystem is extremely important to achieve proper system bonding.

Concrete must be clean, free of contaminates, acids or alkalines prior to primer application. Proper preparation must be performed for metals and other substrates. Call our Tech Support Group for assistance in application and preparation. It is always best to perform a test within a small section of the application area prior to full scale engagement.

This technical data information is accurate to the best of our knowledge. SuperSkinSystems™ Inc. makes no warranty, expressed or implied within the materials on this website, its use or with its any application. SuperSkinSystems™ Inc. shall not be liable for material or application related injuries, material non-conformance, application failures or any consequential damage by the use of this product.
